Commentaires récents
Davy Smits
Davy Smits il y a 2 minutes
Is the webpage accesable if the rest of the clock is not attached, or does it first has to run its diagnostics - eg set the reels to zero etc etc
Pinball Clock [180307-1]
BreedJ il y a 2 heures
I had to redo my pcb design becasue of noise issues. That took some time. I'm know in the progress of writing the first lines of code for the firmware. I'm currently doing that using Platform IO with Visual Studio Code and the Arduino framework after trying some other frameworks and the EDP-IDF as well. The arduino framework might be the best choise for this project. I had some trouble with the SPI interface. Information on the internet about the ESP32 is not always correct. A lot of information says the SPI clock can be up to 40MHz and even up 80MHz. That is not entirely true. These frequencies are only when writing to a slave. When reading data from a slave the maximum us 26.6MHz. It also takes 3us to start the transaction and another 3us to end it. Eventually I managed to get around 100ksps from the ADC, 2 channels simultaneously. Unfortunatly I am not able the use the full 250ksps bandwidth of the ADC. I will need an FPGA for that, but I think 100ksps is enough for most of us. I'm currently busy writing the data aqcuisition part with sample averaging and the triggering for the oscilloscope mode. I already have a bit experience with that after writing the software for the Network Connected Signal Analyzer project a few years ago. My aim is to get a measurement resolution of 0.01db with this project.
2 Channel RF power meter with Wifi, Bluetooth, SD card and touch screen
BreedJ il y a 3 heures
You are right there is a mistake in that revision I forgot to change in that revision. Thank you fot letting me know. If you have any other problem, let me know if I can help.
GPS assisted 10 MHz frequency reference
Jochen Neller
Jochen Neller il y a 4 heures
Hallo,clock is connected with WIFI, but clock doesn`t work (only g-segments are lighting, - - - - - -  )puTTY shows (again and again):DNS_Host_By_Name_CB: -> no IP addressNTP_StartDNS_Host_By_Name_Init: err -5, pendingElektor page shows a (new) link to:  are following lines from your manual still okay? :ntp set hostname ""ntp set addr set method hostnamePlease could you help?Vielen Dank!Jochen
6-digit VFD Clock with ESP32
Kiffie il y a 7 heures
I am not aware of such a project (but I did not actively search for it). However, it should be quite easy to build an SPDIF input based on a standard SPDIF reciever chip and an USB Microcontroller. I will think it through and, maybe, open a new project.
USB-SPDIF Interface – [180027]
